Automatic nozzle
FLOWMATIC Compact Aluminium

High Pressure nozzle

Although EN15182-2 certified (PN16 nozzles), the compact nozzles also comply with the requirements of the standard on PN40 high-pressure nozzles.

A powerful narrow spray for attack

Powerful full cone spray for smothering flames. It is composed of very fine drops propelled at high speed through metal fixed teeth.

Flow rate control by slide valve

Unlike the ball valve, the slide valve preserves a high quality stream during a partial opening of the nozzle.

From straight jet to protective jet in 1/4 turn

Design that allows going from a solid jet to a protective spray jet in just a quarter turn of the bumper.
Product features
Technical sheet
Associated products
Download

PRODUCT CHARACTERISTICS

Designed for unparalleled efficiency, the FLOWMATIC Compact nozzle has a pressure regulation system that optimises its range of action even in case of pressure drop, and allows the user to perform pulsing, starting at 2 bar.

The extremely easy-to-use flow control handle with slide valve, allows the user to vary the flow rate without producing jet deformation.

GENERAL CHARACTERISTICS

Type
Automatic
Weight
1’’ & 1.5’’ = 1.75 kg
1.85kg = 2’’
Available models
FlowMatic 150: 0 - 150 l/min @ 6 bar 1'' BSP F
FlowMatic 250: 0 - 250 l/min @ 6 bar 1'' BSP F
FlowMatic 400: 0 - 400 l/min @ 6 bar 1.5'' BSP F
FlowMatic 400: 0 - 400 l/min @ 6 bar 2'' BSP M
Flowmatic 500: 0 - 500 l/min @ 6 bar 1,5'' BSP F
Dimensions W x D x H
1’’ & 1.5’’ = 29 x 12 x 23cm
2’’ = 31.5 x 12 x 23cm
Pressure
6 bar
Available inlets
2'' BSP M
1.5'' BSP F
1'' BSP F
Material
Hard anodised aluminium
Size
Compact
Valve
stainless steel slide valve
Bumper
polyurethane
Positions
6
Nominal pressure
40 bar
Special features
AA (Air Force) version available
flush position at bumper available

Product reference
